YSV Series

YSV10

3/2 Way

Orifice ∮0.6mm

Direct Operating

Manifold Mounting

YSV20

3/2 Way

Orifice ∮1.1mm

Direct Operating

Manifold Mounting

YSV200

3/2 Way, M5

Orifice∮1.1mm

Direct Operation

High Durability

YSV300

3/2 Way, 1/8"

Orifice∮1.5mm

Direct Operation

High Durability

SF Series

SF1000

5/2, 5/3, 3/2 Way

Port : M5x0.8

15mm Body Width

Flow 200ℓ/min(5bar)

SF2000

5/2,5/3,3/2 Way

Port : G 1/8"

18mm Body Width

Flow 700ℓ/min

SF3000

5/2, 5/3 Way

Port : G 1/8"

23mm Body Width

Flow 760ℓ/min(5bar)

SF4000

5/2, 5/3, 3/2 Way

Port : G 1/4"

26mm Body Width

Flow 1000ℓ/min



SF5000

5/2,5/3,3/2 Way

Port : G 3/8"

32mm Body Width

Flow 2000ℓ/min

(5 bar)

SF6000

5/2, 5/3 Way

Port : G 1/2"

36mm Witdh

Flow 3500ℓ/min

(5 bar)

SC Series

SC200_M5

5/2, 5/3, 3/2 Way

Port M5x0.8

10mm Body Width

Flow 130ℓ/min (5bar)

SC300_1/8"

5/2, 5/3, 3/2 Way

Port G 1/8"

Port M5x0.8 (3/2 Way)

15mm Body Width

Flow 500ℓ/min(5bar)

SC400_1/4"

5/2, 5/3, 3/2 Way

Port G 1/4",1/8" (3/2 Way)

18mm Body Width

Flow 900ℓ/min (5bar)

Converter & Booster

YCT (Air Hydro Converter)

Models:

YCT63

YCT100

YCT160

Usage Pressure 3~7bar

Guaranteed Internal Pressure 10.5bar

YNBH3 (Direct Compressed type Booster)

YNBH3 (Precompressed type Booster)



SN Series (Namur Valve)

SN3000

5/2, 5/3 Way, Port G 1/4

23mm Body Width

Flow 1000ℓ/min(5bar)

NAMUR Mounting

SN4000

5/2, 5/3 Way, Port G 1/4

30mm Body Width

Flow 1800ℓ/min(5bar)

NAMUR Mounting

SIV Series (ISO Valves)

SIV200 (ISO-0 15407-1)

5/2, 5/3 Way

Sub-base, Manifold Mounting

18mm Body Width

Flow 700ℓ/min(5bar)

SIV300 (ISO-0 15407-1)

5/2, 5/3 Way

Sub-base, Manifold Mounting

26mm Body Width

Flow 1000ℓ/min(5bar)

SIV400 (ISO-1)



5/2, 5/3 Way

Sub-base, Manifold Mounting

40mm Body Width

Flow 1600ℓ/min(5bar)

SIV500 (ISO-2)

5/2, 5/3 Way

Sub-base, Manifold Mounting

50mm Body Width

Flow 3500ℓ/min(5bar)

SIV600 (ISO-3)



5/2, 5/3 Way

Sub-base, Manifold Mounting

64mm Body Width

Flow 5000ℓ/min(5bar)
